VERTICAL LIFT STAGES

MLVS SERIES

IntelLiDrives Vertical Lift Stage Platform offers precise vertical translation for payload elevation. A unique wedge design converts horizontal motion, generated by a ball screw drive, into true vertical elevation of the platform. Precision bearings provide platform stiffness and stability while the ground ball- screw mechanism assures positioning accuracy.

      SPECIFICATIONS

• True vertical lift platform

• 5 mm vertical lift

• 10 Kg load capacity

• Repeatability 0.5 micron

• Wedge / ball-screw drive mechanism

• Stepper or brushless servo motor

• Encoder and travel limit sensors

• Vacuum/cable pass-through channel

• Multi-axes lift-rotary systems available
