linear positioning      Key Features:


· Turn-key solution

· Direct linear positioning
· High speed
· Brake option
· Long stroke
· Cable track
Request catalog





Model     LSSE-200-850 LSSE-200-1300

Peak force (note1) Fp N 850 1300

Continuous force (note 2) Fc N 400 600

Max speed at Fp @ 220 VAC Vp m/sec 2.6 1.7

Accuracy (note 3)   mkm 5 - 50

Resolution (note 3)   mkm 0.1 - 25

Repeatability (note 3)   mkm 0.5 - 10

Forcer weight Kg 4.5 6.5

Max payload weight   kg 40 60

Stage profile (cross-section)   kg 180 x 200

Max stroke (note 4)   m 2


note 1 duration 1 sec
note 2 coil at 120°C
note 3

dependent on encoder type and travel length.
